מאפיינים עיקריים

• Channels (Mono + Stereo) 18 + 4
• Auxiliarys (MON, FX, AUX) 2 Pre, 2 Post, 2 Pre/Post switchable
• MIC GAIN (Mono / Stereo) 0 to +60 dB / +10 to +60 dB
• LINE/CD/USB GAIN (Stereo) -10 to +20 dB
• THD, at 1 kHz, MBW = 80 kHz
• MIC input to Master A L/R outputs, +16 dBu, typical < 0.005%
• Frequency Response, -3 dB, ref. 1 kHz, any input to any Mixer output 15 Hz to 70 kHz
• Crosstalk, 1 kHz
• Fader & FX/AUX/MON-Send attenuation > 85 dB
• Channel to Channel < -80 dB
• CMRR, MIC input, 1 kHz > 80 dB
• Input Sensitivity, all level controls in max. position MIC / LINE (Mono) / LINE (Stereo) / CD (Stereo) -74 dBu (155 µV) / -54 dBu (1.55 mV) / -34 dBu (15.5 mV) / -34 dBu (15.5 mV)

• Maximum Level, mixing desk
• MIC inputs +21 dBu
• Mono Line inputs / Stereo Line inputs +41 dBu / +30 dBu
• All other inputs +22 dBu
• All other outputs +22 dBu

Input Impedances

• MIC / Insert Return 2 ㏀ / > 3.3 ㏀
• 2Track Return & CD In 10 ㏀
• All other inputs > 15 ㏀

Output Impedances

• Phones 47 Ω
• All other outputs 75 Ω
• Equivalent Input Noise, MIC input, A-weighted, 150 ohms -130 dBu
• Noise, Channel inputs to Master A L/R outputs, A-weighted
• Master fader down -97 dBu
• Master fader 0 dB, Channel fader down -87 dBu
• Master fader 0 dB, Channel fader 0 dB, Channel gain unity -81 dBu

Equalization

• LO Shelving ±15 dB / 60 Hz
• MID Peaking, mono inputs ±15 dB / 100 Hz to 8 kHz
• MID Peaking, stereo inputs ±12 dB / 2.4 kHz
• HI Shelving ±15 dB / 12 kHz
• Master EQ 11-band (63, 125, 250, 400, 630, 1k, 1.6k, 2.5k, 4k, 6.3k, 12kHz) ±10 dB / Q = 1.5 to 2.5

Power Consumption

• without lamp / with lamp 55 W / 60 W

Filter

• LO-CUT, mono inputs f = 80 Hz, 18 dB/oct.
• VOICE FILTER, mono inputs switchable
• FEEDBACK FILTER, MON 1/2 70 Hz to 7 kHz, Notch, -9 dB

Effects

• Type, effects presets Dual stereo 24/48-bit multi effects processors, 100 Factory + 20 User, Tap-Delay
• Remote control Footswitch, MIDI
• Display 128 x 64 pixels, OLED

Digital Audio Interface

• Channels 4 In / 4 Out
• AD/DA Conversion, Sampling Rate 24-bit, 44.1 / 48 / 88.2 / 96 kHz
• PC Interface USB2.0, Female Type B
• MIDI Interface 5-pin DIN connector, In / Out

Protection

• Mixer Outputs (Relay controlled) MON 1, MON 2, MASTER A
• Switching Mode Power Supply (µC controlled) Mains Over/Undervoltage, High Temperature
• Phantom Power, switchable in groups 48 V DC
• Power Requirements (SMPS with auto range mains input) 100 V to 240 V AC, 50 Hz to 60 Hz
• Dimensions (W x H x D, without lid), mm 818.5 x 155.0 x 498.5
• Weight, without lid 14.5 kg

Optional Accessories

• Dust Cover for CMS 2200 DC-SH2200-3
• Gooseneck Lamp, 12V/5W, 12”, XLR 4 pol. DC-LITLITE-4P
• FS 11 (Footswitch with LED) DC-FS11
