ACOUSTICAL SPECIFICATIONS

• Frequency Response:45 Hz ÷ 20000 Hz
• Max SPL @ 1m:130 dB
• Horizontal coverage angle:90°
• Vertical coverage angle:60°

TRANSDUCERS

• Compression Driver:1 x 1.0”, 1.75” v.c
• Woofer:15”, 2.5” v.c

INPUT/OUTPUT SECTION

• Input signal:bal / unbal
• Input connectors:XLR, Jack
• Output connectors:XLR
• Input sensitivity:-2 dBu/+4 dBu
• Mic. Input Sensitivity:-32 dBu

PROCESSOR SECTION

• Crossover frequencies:1600
• Protections:Thermal, RMS
• Limiter:Soft limiter
• Controls:Volume, Boost, Mic/Line

POWER SECTION

• Total power:1400 W Peak
• High frequencies:400 W Peak
• Low frequencies:1000 W Peak
• Cooling:Convection
• Connections:VDE

STANDARD COMPLIANCE

• Safety agency:CE compliant

PHYSICAL SPECIFICATIONS

• Hardware:2 x M10
• Handles:1 on top, 1 each side
• Pole mount/Cap:Yes
• Color:Black

SIZE

• Height:708 mm / 27.87 inches
• Width:437 mm / 17.2 inches
• Depth:389 mm / 15.31 inches
• Weight:19.6 kg
