Nominal Diameter12″Power Handling (RMS)500 Watts
Power Handling (max)1000 WattsImpedance8 ohms
Frequency Response55 to 3,000 HzSensitivity100 dB 1W/1m
Voice Coil Diameter3″
Thiele-Small Parameters
Resonant Frequency (Fs)54 HzDC Resistance (Re)5 ohms
Voice Coil Inductance (Le)1.4 mHMechanical Q (Qms)3.8
Electromagnetic Q (Qes)0.18Total Q (Qts)0.18
Compliance Equivalent Volume (Vas)1.6 ft.³BL Product (BL)26.4 Tm
Diaphragm Mass Inc. Airload (Mms)75gMaximum Linear Excursion (Xmax)7 mm
Surface Area of Cone (Sd)522 cm²
