תיאור

Power 60W RMS per channel, 8ohms, 1KHz, <0.05% THD. 100W RMS per channel, 4ohms 1KHz, 0.05%THD.

Frequency Response 20Hz to 20KHz, 0.5dB. Signal to Noise Ratio……106dB, 20Hz to 20KHz, Unweighted.

Minimum Load 4 ohms. Damping Factor……>150 at 8 ohms. Slew Rate…… >20V/us

Connectors 5mm screw lock captive screw connector, 4 poles. Protection……Thermal, Clip, Output shorting.

INPUT

Sensitivity  .+4dBu for full output. Impedance……>10K ohms balanced/unbalanced. Voltage Gain……24dB.

Max. Input level .+21dBu. Channel separation……>78dB. CMMR……>80dB. Control……Each channel by trimmer pot.

Connectors  Balanced via RJ45 screened connector (In / Out for other units connection), Unbalanced via RCA connector.

POWER

Mains requirements  100 VAC to 240VAC 50/60 Hz. Mains socket……Standard IEC

Typical consumption 40 Watts at 1/4 power, 8 ohms. Quiescent…… 8 Watts Standby……<3W

CONTROL / REMOTE / INDICATIONS

Control/ Input port RJ-45 socket, connection by CAT-5 screened cable. Mute……Pin 5 connected to ground (Pin 7)

Standby Pin 4 connected to ground (Pin 7) or automatically after about 5 minutes without signal.

12VDC For external devices as Hubs, Mixers, Players, etc. Maximum consumption 300mA.

Signal Presence of signal input of at least -24dB. Limiter/Protect……LED indicator of clip limiting or thermal / short protection.

GENERAL

Structure……Metal case with convection aluminum heat sink cooling.

Mounting 1U rack or 1/2 with 2 short / long “ears”. On wall & under table with 4 short “ears” (Supplied), table top with rubber legs.

Dimensions H 4.4cm x W 21.6cm x D 19.2cm. (1/2 rack wide , 1U) Weight……Net = 1.2Kg, Shipping = 2.88Kg

Operating conditions -10°C to +50°C Temperature, 10%-90% Humidity. MTBF……300,000 HOURS
